Mytek Brooklyn AMP+

Description

Brooklyn AMP+ retains the same type of sound with dynamic and precise transients and even and extended frequency response, but with way less low level distortion and cleaner natural, analog like character with deeper, larger soundstage.

Brooklyn AMP + features new faster transistors, cutting the so called "switching dead time” to low nanoseconds and faster and higher, 650kHz carrier clock. They both contribute to greatly improved low level detail and lower distortion. In addition the output filter frequency has been increased two fold for lighter highs and to better accommodate difficult loads.

Brooklyn AMP+ is a reference power amplifier with signature Mytek sound - musical, detailed and transparent. Its dual mono design breaks the sound quality spell associated with Class D and proves a well executed Class D circuits can challenge the best Class A and sound amazing. Amplifier is packaged in miniature 1/2 rack enclosure and it's small enough to fit in a briefcase, yet powerful to drive the largest speaker systems. It's designed to be used as regular stand alone power amplifier or to complement Brooklyn DAC for complete modern digital streaming and vinyl playback system.

Brooklyn AMP+ is another brand new, amazing sounding product from Mytek. Mytek golden ear expertise was used to design world’s most likely best sounding Class D amplifier. Mytek engineers with the lead designer, Michal Jurewicz, have demonstrated that a carefully executed Class D can sounds like triode, with beautiful midrange and depth while maintaining deep bass and fast transient and detail. Mytek extensive expertise with DSD, technology similar to digital amplifiers was used in this project. This architecture allows for packing a lot of power (300W/ch) into small 1/2 rack chassis, small and light enough to be carried around in a briefcase.

Specifications

POWER RATINGS AT 1% THD:
at 16 Ohm – dual mono 2 x 130 W
at 8 Ohm – dual mono 2 x 250 W
at 4 Ohm – dual mono 2 x 300 W
at 2 Ohm – dual mono 2 x 400 W
Peak – dual mono 2 x 1200 W

OUTPUT SWING:  70 Vp / 140 Vpp (unloaded)

SNR: >121 dB

FREQUENCY RESPONSE -3dB: 10Hz – 30kHz

THD REGULAR USE: <0.01%

PROTECTION CIRCUITRY: Short circuit protection, DC protection, under voltage protection, temperature protection, overload protection

DAMPING FACTOR: >400

DC POWER ON TRIGGER: 12VDC minijack

WORLDWIDE POWER SUPPLY: 100-240VAC 50/60 Hz

DIMENSIONS: WxDxH=8.5×9.5×1.74”=216x241x44mm

WEIGHT: 6lbs, 3kg

WARRANTY: 2 years
