Mytek’s Brooklyn Bridge takes the sound we love from the Brooklyn DAC+, adds network streaming (WiFi and ethernet) and USB host capabilities to fit perfectly in a modern music system. Add the Mytek Brooklyn AMP+ to drive your stereo speakers, and attach it to our new GS-X mini and have an incredible balanced headphone system in a desktop footprint.
The Mytek Brooklyn Bridge is identical to Brooklyn DAC+ in terms of audio circuits and performance but has the addition of a built-in Network Streamer. AES/EBU digital input is replaced with an ethernet network connector, a WiFi antenna and a USB port for external music hard drive. Just add a tablet (iPad or Android) for a complete music system to stream Tidal MQA, Qobuz Hi-Res or other streaming services or play local files connected to the Brooklyn Bridge USB port. Roon requires additional Roon Core. Like in the Brooklyn DAC+ there is a line and phono analog preamplifier and a reference headphone amplifier.
CONVERSION: up to 384k, 32bit PCM, native DSD up to DSD256, DXD, 130dB DR, ES9028PRO chipset
MQA HI-RES DECODER: built in certified hardware MQA™ decoder, full unfold to original sample rate
NETWORK INPUTS: Ethernet CAT5 (PCM up to 24/192k, DSD64 , WiFi (PCM up to 24/192k, DSD64)
DIGITAL INPUTS: USB2 Class2 (OSX, Linux driverless, all formats up to 384k), 2x S/PDIF (PCM up to 24/384k, up to DSD128 DOP), Toslink (up to 24/176k, DSD64 DoP)
CLOCK: “Mytek Femtoclock Generator™” 0.82ps internal jitter.
ANALOG OUTPUTS: RCA, balanced XLR, simultaneous, 75 Ohm impedance
HEADPHONE OUTPUTS: Reference High Current, High transient Headphone Amp, 500mA, 6 Watts, dual headphone jacks, designed to drive hard-to-drive headphones.
BUILT-IN ATTENUATOR: Choice of 1dB step analog attenuator, separate for main out and headphones, 1dB step digital 32 bit attenuator and purist relay bypass.
BUILT-IN ANALOG PREAMP: Line level input or Phono M/M, M/C input, relay controlled.
AUDIO INTERFACE FUNCTION: All digital inputs can be routed into computer via USB2. Allows connection of external digital sources such as CD Players and digitizing ADCs.
REMOTE: Included, universal remote capable
Mytek began building consumer-oriented DACs in 2011, and now boasts a full line of home hi-fi products named for New York boroughs and landmarks, like the flagship Empire Streamer DAC, and new all-in-one Brooklyn Bridge II Roon Core. Mytek designs their DACs to a strictly neutral reference, such that the signal on the recording is passed through as accurately as possible to the downstream equipment.
