STAX SRM-500T Electrostatic Headphone Amplifier
$1,499.00
Ships in USA
30 Day Returns
Free 1 or 2 Day
Authorized Retailer
STAX is proud to introduce the SRM-500T, successor of the SRM-006tS. The SRM-500T utilizes a pair of 6FQ7/6CG7 vacuum tubes on the output driven by a custom-made noise noise dual FET. This updated design offers improved power efficiency allowing for better sound quality over the conventional vacuum tube output driver unit featured in the SRM-006tS. STAX prides itself in pricing this new electrostatic driver at a great value while still offering the best possible performance!
Features
• FET Input + vacuum tube output hybrid DC amplification
• Newly Designed Vacuum Tube Output Stage
• Custom-Made Low Noise Dual FETs
• Pair of 6FQ7/6CG7 pre-installed Vacuum Tubes
• Pair of RCA input terminals
• Pair of XLR 3-pin input terminals
• RCA parallel output terminals
Technical Specs
Frequency Response
DC - 90kHZ (with one SR-L500 MK2)
Vacuum Tube
6FQ7/6CG7
Harmonic Distortion:
0.01% or less (1kHZ/100Vrms output)
Input Impedance
50k Ohms (RCA) 50k Ohms x2 (XLR)
Maximum output voltage
300Vrms (1kHz)
Bias Voltage
DC 580V
Operating temperature / humidity
32 to 95 degrees fahrenheit @ no more than 90% humidity (non condensing)
Power Consumption
38W
Dimensions
(H)4.0" x (W)7.68" x (L)14.8" (maximum protruding portion included)
Weight
7.5 lbs
